YOUR PARTNER FOR PORTAL MILLING MACHINES
TRIMILL specializes in the design and manufacture of high-speed machining centers for tool, mold, and die machining, as well as for general engineering and the aerospace industry. Our product spectrum includes vertical and horizontal machining centers with travel from (x,y,z) 1,100/1,000/700 mm to 13,500/4,500/1,800 mm in three, five, and multi-axis configurations.
Trimill VS Series
The VS Series 5-axis vertical machining has a tilting 1,200 mm rotary table with a 5,500-pound capacity. The VS1614 gantry machine uses a unique closed crossbar design BOX-IN-BOX construction for very dynamic and precise machining.
Download the Brochure for Additional Information
Trimill VU Series
The VU Series features a TRIMILL trademark of rigidity and thermal stability with its box-in-box gantry design and UHPC (ultra-high-performance concrete) concrete side walls. The result is high accuracy and repeatability. 5-axis machining is achieved with a rotary table and main spindle tilt. For 6-axis machining, rotation of the main spindle head is available. Machining five sides in a single setup with the option to extend the X-axis 39.4”(1,000 mm) increments makes the VU Series a productive choice for large format machining.
Download the Brochure for Additional Information
Trimill VM Series
5-Axis with Changeable Heads – The TRIMILL VM Series has an auto-head change feature. Up to 13 different milling heads can be stored and selected – straight, angled, fork, universal 3-axis, and/or 5-axis machining, each with a specialized milling head. 5-axis operation supports roughing and finishing with a single setup. The VM Series shares the TRIMILL trademark of rigidity and thermal stability with its box-in-box gantry design and polymer concrete side walls, ensuring high accuracy and repeatability.
Download the Brochure for Additional Information
Trimill VF/VFC Series
5-6-Axis with Fixed Table – The VF Series shares the TRIMILL trademark of rigidity and thermal stability with its box-in-box gantry design, UHPC (ultra-high-performance concrete) concrete U-shaped based with sidewalls, resulting in high accuracy and repeatability.
*VFC Series does not require a dedicated foundation.
Download the Brochure for Additional Information
